LED Streetlight
Product Code: 480
Description
Functional modern LED streetlight in 3 sizes and multiple wattages with adjustable mastfitter or wall mounting. Excellent Rear Shielding to prevent Light Spill on Perimeters.
Construction
Construction: Aluminium and PMMA. IP66. IK09. Class 1. LEDs and Driver are not accessible for maintenance or replacement. Product not suitable for Marine areas (ie. within 1km of sea).
Installation: Mastfitter for Post top or Side entry mounting. 76mm and 60mm versions available. 76mm typically for Post-top and 60mm for Side Entry.
Optional adjustable tilt angle from -15º to + 15º.
Finish: Light Grey RAL 9006 as standard.
Optic: Street Optic as standard. Forward Throw Optic available for selected wattages.
Manufactured: EU.
Product Compliance: EN 60598, CE.
Options
Various Optics
Electrical
LED: 14w to 167w high power LED 4000K CRI>70 as standard. Other CCT or CRI on request. Lifetime: L90 B10 100,000 Hours @ 25ºC
Driver: 190-264V AC 50/60 Hz. Integrated in luminaire and is not changeable. 4kV Surge protection included.
Downloads
Product Leaflet: Download Product Leaflet
PHOTOMETRICS:
– 5LSA13LGA – 61w LED – Street Optic
– 5LSA16LGA – 73w LED – Street Optic
Several other Optics available.
ALTERNATIVES:
Download Product Leaflet no. 610 – Durostar Streetlight
Competitively priced, but designed for 50,000 hour life.
