Area Pole-top Light
Product Code: 388
Description
Architectural LED post-top luminaire for residential or pedestrian areas, gardens, parks, etc.
Construction
Construction: Made of injected cast aluminium and polycarbonate. IP66. IK10. Hood is removable for access/maintenance.
Lens: Polycarbonate.
Installation: Post-top on 60mm Diameter Spigot (70mm high).
Finish: Grey RAL 9006 as standard, other colours on request.
Manufactured: EU.
Product Compliance: EN 60598, CE.
Options
Various Optics, DALI, Photocell, Programmable dimming, CLO, Wall mounting option on request, choice of pole / wall brackets, motion detector, etc. Removable LED Diffuser included as standard.
Electrical
LED: 11w to 73w LED. 4K as standard, 3K on request. Symmetric Optic (C4 or C5) as standard, other distributions on request.
Life: L70 B10 >100,000 hours. (73w version at 25°C).
Driver: 700mA as standard. 350mA or 500mA on request.
Mains Surge Protection: 10kV device included as standard.
Downloads
Product Leaflet: Download Product Leaflet
Photometrics: see Lighting Design note.
– 5CHI11LGA – 28w LED -Symmetric Optic
– 5CHI13LGA – 36w LED -Symmetric Optic
– 5CHI17LGA – 69w LED -Symmetric Optic
Several other Optics available.
